A Disruptive Low Cost
Semiconductor Model
about us
Fabless Semiconductor Company
Focused on Ultra Low Power and Innovative Wireless Solutions (RFID, NFC and BLE) designed to help our customers to succeed in their IoT markets.
Our Vision
People will be more and more connected, World will require low power and green wireless connections. ChipIC is prepared for the current and future challenges. It is your partner for cost-effective ASIC design and turnkey manufacturing.
Our Mission
Founded by experts in RFID having a strong industrial experience of complete supply chain from design to mass production. Lead IC developments for state of the art solutions :
- Enhancing wireless application performances
- Empowering energy harvesting capabilities for battery less systems
Core Business
Based on Team’s strong experience
IP Developments
RF, RFID, UWB, Energy harvesting
ICs and ASICs
Tailored and Customized solutions. Robust design practices and smooth ramp up to mass production.
Consulting services
Speed up our customers time to market. From specification to mass production
ChipIC Value Proposal
Based on Team’s strong experience
creative
Develop high sensitive and more robust wireless interfaces. Simplify solutions to get maximum of benefits from the used elements. Team up with the best teams to design state of the art solutions.
Transparent
Provide to customers the most cost effective chip, eliminate margins, intermediates over all the supply chain. Get access to world wide wafer fabs, test houses, back-end operations. Simplify democratize semiconductor supply chain.
Secure
Security is part of our mindset, secure your data and your business. Strong established relationships with the main foundries.
Products RFID IPs
Low Frequency RFID AFE
Compliant with ISO/IEC11784-85 and ISO/IEC14223 standards.
High Frequency NFC
(Near Field Communication)
AFE compliant with following standards :
- ISO/IEC15693
- ISO/IEC14443
- ISO/IEC18000-3
- NFC Forum
UHF RFID, ePC AFE
Compliant with following standards :
- ISO/IEC18000-63
- ePC Class 1 Gen 2 V2
IC and ASIC Developments
- Listen and understand customer requirements
- Define the product specification
- Select the key design elements
- Chose the technology node and wafer fab
- Optimize IC test and back-end operation
- Design the IC, IP
- IP integration and verification
- Full chip layout
- Test and Package development
- Quality and Reliability
- Production Logistics Management
Consulting Services
One Stop Shop
From designs to Mass Production Management Project Evaluation
- Improve performances
- Secure customer IP & Longevity
- Cost savings
NETwORK PARTNERS
Strong relationships with main foundries, test houses and back-end players
EXPERIENCE
Skilled and motivated team operating over 20 years with RFID and wireless projects
Cost reduction
Improved delivery lead times, mature manufacturing technology.
CUSTOmER SATISFACTION
Contact us
We are based in Switzerland, country with strong tradition in accuracy
